Need some help Technical Drawings!!!!
Posted
#1090428
(In Topic #130461)
![Avatar](https://vwgolfmk1.org.uk/themes/default/images/ocf_default_avatars/default_set/cartoons/half-life.jpg)
Old Timer
![jellybelly in the usergroup ‘Paid Member’ jellybelly in the usergroup ‘Paid Member’](https://vwgolfmk1.org.uk/themes/default/images_custom/7vW13sh.png)
![jellybelly in the usergroup ‘Regional Hosts’ jellybelly in the usergroup ‘Regional Hosts’](https://vwgolfmk1.org.uk/themes/default/images_custom/MkOEmwK.png)
![jellybelly in the usergroup ‘Old timer’ jellybelly in the usergroup ‘Old timer’](https://vwgolfmk1.org.uk/themes/default/images_custom/XW2jYK6.png)
Need some help Technical Drawings!!!!
need a bit of help
i need a line drawing of a mk1 tintop or cabby
something that i can use to draw in autocad so that i can get it cnc'd out
you could say that i'm up to something!!!!!
![:lol:](https://vwgolfmk1.org.uk/themes/default/images/ocf_emoticons/lol.gif)
So looking for something like in the bentley manual nice techincal drawing of the body side on and from the front and rear or just a good line drawing that someone has done
![:)](https://vwgolfmk1.org.uk/themes/default/images/ocf_emoticons/smile.png)
thanks for your help
![:)](https://vwgolfmk1.org.uk/themes/default/images/ocf_emoticons/smile.png)
